Industrial Body Cream Making Machine / Lotion Manufacturing
Equipment
Body Cream Making Machine Advantages:
-Discharging way
Emulsifier pot cover is lifted up and down through
hydraulic/electric system. The finished products are discharged by
following ways: turn over the pot for discharging, pressurized the
pot to discharge the materials from the bottom outlet with the help
of the delivery pump.
-Temperature Control
Using the electricity heating bar to heat the thermal medium inside
the jacket to heat the material. The heating temperature is
settable and can be controlled automatically. It is also ok to
input steam for heating and input cooling water to the jacket for
cooling the materials down, easy to operate.
-Mixing way
Homogenizer and blade agitator can be used separately or at the
same time. The micronization, emulsifying, mixing, dispersing of
materials can be finished in a short time.
Body Cream Making Machine Parameter
· Capacity:350L
· Material: material contact part SS316L, material non-contact part
SS304.
· Customized service: to provide and design total solution as per
customer URS
Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine
Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump
After finish one batch, customer can choose positive pressure or
rotor pump for material out.
Body Cream Making Machine Parameters
Model
| Capacity | Emulsifying motor | slow mixer motor | Machine dimension |
KW | RPM | KW | RPM | LENGTH | WIDTH | HEIGHT | Lifting hight |
| ZRJ-500 | 500L | 7.5 | 1150-3500 | 2.2 | 10-40 | 4000 | 2800 | 2700 | 4000 |
| ZRJ-350 | 350L | 7.5 | 1150-3500 | 2.2 | 10-40 | 3700 | 2650 | 2550 | 3600 |
As a professional manufacturer and exporter, DingYi I/E Industrail
Co., Ltd Engages in the research, design, manufacture and sale of
various machines.
