50-10000L Vertical double jacketed stainless steel mixing agitator tank

Product Description:

Reaction mixing tank is essential equipment in daily chemical industry. It is suitable for the mixing of different materials, such as the production of shampoo, bath liquid, etc.

Applied Field:

1. Cosmetics industry:

Cream, shaving cream, sunscreen, lotions, essence, moisturizing cream, hand cream, etc.

2. Daily chemical industry:

Laundry detergent production, shampoo, toothpaste, liquid soap, detergent, etc.

3. Pharmaceutical industry:

Emulsion, ointment, oral syrup, oral liquid, etc.

4. Food industry:

Fruit jam, cheese, ketup, mayonnaise, baby food, chocolate cream, syrup, etc.

Stainless steel mixing tank features:

1. Optional PLC touch screen

2. Frequency converter for speed adjustment.

3. Inside surface is Ra ≤0.4μm

4. Outside surface is mirror or matt polish.

5. Electric and steam jacket heating available for user to choose

6. Mixing pot in contact of material made of SS316L and SS304 without dead corner

7. Available with high shear homogenization mixer resulting in high shear and high dispersion force with excellent emulsifying results

Stainless steel mixing tank specifications:

1. Volume: 50-15000L

2. Material: SS316L & SS304

3. Insulation material: rock wool

4. Structure: Jacketed vessel, vessel with jacket and insulation

5. Application: liquid mixing for pharmaceutical, cosmetic and dairy products

6. Components: mixing device, vent filter, temperature gauge, level gauge, manhole, sight glass with lamp and cleaning ball or according to client’s detailed requirement.

Mixing tank as a equipment are suitable for the pharmaceutical & cosmetic industries for
1. Pharmacy industry: Syrup, Suspension, Injection Solution, Eyedrop, oral solution, injection solution,Carbomer of gel.

2. Health product industry: soft gel preparation, etc

3. Cosmetic industry:cream, ointment, lotion,toothpaste, hair color

Capcity: 10L-10000L

Pressure: Atmospheric pressure or pressure vessel (0.1mpa-0.6mpa)

Material: Stainless steel 316L, 304 or special reqirements

Mixing type for choose:paddle mixer, propeller mixer, PTFE scraper mixer, Top homogenizer, bottom homogenizer, bottom magnetic mixer, high shear mixer

Heating Choose:Steam or electrical heating or hot-water circulation.

Structure: signle layer or with insulating layer or with jacket and insulating layer.

Thermal insulation material for choose: PU or rock wool etc.

Jacket type for choose: full jacket, dimple jacket, coil jacket, half pipe.

List of nozzles(for choose): Manhole, CIP and SIP port, pressure gauge, temperature sensor, material inlet, material outlet, respirator(vent filter), sight glass, lamp, handhole, vacuum port, reserve port etc.

CIP: cleaning ball.

SIP: As a option.

Loading cell: use Mettler Toledo as a option.

Control type:
1: button control

2. PLC control:use Siemens PLC S200 (S300 as a option), Siemens HMI(3-LEVEL password and Recipe management as option).
