stainless steel PLC control ZRJ-100L Vacuum emulsifying machinery with Tilting Hydraulic Lift

Product description

Vacuum homogenizer mixer is specially designed adopting advanced technology of oversea according to the cosmetic and pharmaceutical production. The machine is composed of pre-mixing tank (water tank and oil tank), vacuum emulsifying tank, vacuum pump, hydraulic system, discharge system, electronic system and operating platform.

The vacuum emulsifying mixer have characteristic of easy operation, steady capability, good homogeneity, high efficiency, reasonable structure, and high automation level and easy clean.

The vacuum emulsifying mixer machine is used to produce cream products in the cosmetic factory and pharmaceutical factory, especially used to cream and lotion.

· Capacity:100L
· Material: material contact part SS316L, material non-contact part SS304.
· Customized service: to provide and design total solution as per customer URS

Vacuum Emulsifying Machine including:
· Vacuum emulsifying main machine
· Pre-mixing tank for water and oil material
· Vacuum system
· Hydraulic system
· Control system
· Platform made from SS304

Vacuum emulsifying main machine:
· Slow mixer 0-40rpm with PTFE scraper
· Homogenizer 0-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.09Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine

Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump

After finish one batch, customer can choose positive pressure or rotor pump for material out.
