Inline high shear emulsifying homogenizing High Shear Emulsifying
Pump
Pipeline High Shearing-rate Emulsifying Machine and Equipment
Emulsifying machine has head-end suction port, top discharging port
and horizontal cantilever structure.
Sealing: mechanical seal with lower leakage and longer service
life. Single end-face or twin end-face mechanical seal as choice
according to different application, and the twin end-face
mechanical seal can be connected to clean tap water directly.
Characteristics: Higher shearing force, faster emulsifying
procedure, smaller distribution of particle sizes and better
emulsifying stability.
Application of pipelined high shear emulsion pump:
Inline high shear mixer is usually installed in the bottom of the
reactor or pipeline, the material go through form inlet to outlet,
after high-speed shear.
This process could be done continuously or in circulation.
Pipeline high-cutting dispersal emulsification machine is
high-capability equipment producing and circularly treating refined
material. There are 1-3 groups of occlusal multilayer stators and
rotors in the limited cavity. The rotors circumrotate in a high
speed by the motor driving and bring driving suction, which draws
the material into the cavity. In the least time, the material is
dispersed, cut and emulsified. The distributing scale of gains
becomes narrower.
The refined steady products are produced. The capability is large,
so it is fit to continuously produce in the production line. The
distributing scale of gains is narrow and it has high evenness,
high efficiency, low-noise and saves time and energy resources and
runs smoothly, so it can clear up the difference of the products of
different batches.100% material is dispersed and cut, which has the
capability of short-haul and low-lift feeding. It is used and
repaired easily and can realize automatic control.
| Model | Power(KW) | Speed(RPM) | Flow rate(m3/h) | Outlet(mm) | Inlet(mm) | Weight(kg) |
| 4 | 4 | 3000 | 2.5 | DN32 | DN40 | 125 |
| 7.5 | 7.5 | 3000 | 6 | DN40 | DN50 | 170 |
| 11 | 11 | 3000 | 11 | DN50 | DN65 | 225 |
| 15 | 15 | 3000 | 16 | DN50 | DN65 | 260 |
| 18.5 | 18.5 | 3000 | 20 | DN65 | DN80 | 295 |
| Name: | sanitary stainless steel food grade emulsifier inline high shear
pump |
| Material: | SS304 ,SS316 |
| Power | 1.5KW-130KW |
| Connection: | Clamp, Welded, Thread, Flange |
| Packing: | Plywood , customized |
| Motor: | ABB,Domestic motor |
| MOQ: | 1 set |
| Max. Loading Capacity: | 50-50000L |
Packaging Details:
| As per the request of customers
|
Delivery details:
| Uaually within 50-60 days after receiving T/T down payment |
