stainless steel 316L Jet type Industrial Vacuum Mixer for shower gel

Product description

The features of ZJR Vacuum Homogeneity Emulsifier are:

The tank cover is automatic rising type, the material was directed draw into the emulsifying tank from oil tank and water tank based on a pipe that is under vacuum, the discharge is based on the turn the emulsifying tank. And the heating system is electric heating or steam heating that the temperature is automation control. Put the cool water into the intercalated bed so cooling the material, simple operation and safety (at the outside have a warm layer). The homogenizer and the blade stirring can together work or separate work.

1 Advanced PLC touch screen control is optional.

2 The emulsifying pot lid can adopt hydraulic lifting system, easy to clean and the cleaning effect is more obvious, the emulsifying pot can adopt tilting discharge or use rotor pump for material out .

Vacuum emulsifying main machine:
· Slow mixer 0-40rpm with PTFE scraper
· Homogenizer 0-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.093Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine

Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump

After finish one batch, customer can choose positive pressure or rotor pump for material out.

NOTE: Due to make toothpaste, the motor power have different type, so pls contact us, we will choose a suitable machine for you. we have engineer work for toothpaste factory more than 10 year also have machinery design experience.

As a professional manufacturer and exporter, DingYi I/E Industrail Co., Ltd Engages in the research, design, manufacture and sale of various machines.

Our factory specializes in making kinds of pharmaceutical, cosmetic and food machinery, for instance, Vacuum emulsifying mixer, Suppository vacuum emulsifier, Toothpaste making machine, Tube filling and sealing machine, Bottom homogenizing cream mixer, Soft gel preparation system, Dry type granulator, Color mixing machine, CIP cleaning system, Stainless steel mixing and storage vessel, Gel storage tank, Online high-shear emulsifier, Sanitary rotor pump and centrifugal pump, Colloid mill, water and powder mixer, Belt conveyor.


Our company always contributes to produce products satisfying customers.

We are very pleased to cooperate with you to create our bright future.
